PAR1810-IP
Par1810 IP is an IP65 waterproof LED PAR light with 18pcs 10W RGBW 4 in 1 LEDs, 25°/40° beam angle, 4/8CH DMX control modes, DMX512, Auto mode, Master-slave control, 0-100% linear dimming and 1-25Hz electronic strobe.
| Power consumption | 200W |
|---|---|
| Power input | AC100-240V, 50-60Hz |
| Light source | 18pcs 10W RGBW 4 in 1 LEDs |
| LED configuration | 18pcs 10W RGBW 4 in 1 LEDs |
| Color system | Uniform RGBW color mixing; Color change speed: 0-20Hz; Red, Green, Blue, White color temperature preset; RGBW LED |
| Beam angle | 25°/40° |
| Control | DMX512; Auto mode; Master-slave; Manual RGBW color mixing |
| DMX channels | 4/8CH |
| Dimming | 0-100% linear dimming |
| Strobe | Independent electronic strobe, 1-25Hz |
| Display | Digital display; MENU / UP / DOWN / ENTER buttons |
| IP rating | IP65 |
| Working temperature | -20℃ to 50℃ |
| Housing material | High-strength die-cast aluminum alloy |
| Product size | 32 x 24 x 21.5cm |
| Net weight | 4.8KG |
Specifications are based on the current Par1810 IP product record and may change without prior notice. CRI, Luminous flux, Packing size, Gross weight, Certification, Warranty, MOQ, Lead time require final sales confirmation.
Product questions
What type of fixture is PAR1810-IP?
PAR1810-IP is a LED PAR Light. Par1810 IP is an IP65 waterproof LED PAR light with 18pcs 10W RGBW 4 in 1 LEDs, 25°/40° beam angle, 4/8CH DMX control modes, DMX512, Auto mode, Master-slave control, 0-100% linear dimming and 1-25Hz electronic strobe.
What light source does PAR1810-IP use?
The published light-source specification for PAR1810-IP is 18pcs 10W RGBW 4 in 1 LEDs.
What is the IP rating of PAR1810-IP?
The published protection rating for PAR1810-IP is IP65. Confirm installation conditions and the latest production specification with iTOPLITE before use.
What beam or zoom range does PAR1810-IP provide?
The published optical range for PAR1810-IP is 25°/40°.
Which DMX channel modes does PAR1810-IP support?
The current product record lists 4/8CH. Contact iTOPLITE for the latest DMX chart and firmware-specific documentation.
Where is PAR1810-IP typically used?
Recommended applications include Outdoor events, Stage performance and concerts, Wall washing and decorative lighting, Clubs, bars and rental projects. Final fixture selection should account for throw distance, required output, control plan and environmental conditions.
Planning with PAR1810-IP
Overview
PAR1810-IP is a led par light in the LED PAR range. Its published light-source specification is 18pcs 10W RGBW 4 in 1 LEDs, the optical record lists 25°/40°, and the enclosure rating is IP65. The available control record lists 4/8CH. These values describe the current product record and should be checked against the production version offered for a project. Selection should begin with the required visual task and site conditions rather than one headline value.
Where it is used
The published applications include Outdoor events, Stage performance and concerts, Wall washing and decorative lighting, Clubs, bars and rental projects. In a real design, each application changes the priorities. Touring teams may focus on handling, repeatable setup and control-library consistency. Fixed installations may give more weight to access, operating cycles and planned maintenance. Outdoor work also requires compatible connections, distribution and procedures; the fixture rating does not protect unrelated parts of the system.
Reading the specifications
The 25°/40° optical specification should be evaluated at the actual throw distance and target size. Request photometric data or test a production-representative sample when beam coverage or camera exposure is critical. The published IP65 rating describes enclosure protection under defined conditions, not permission to ignore mounting orientation, seals, connectors or severe-weather decisions. The 4/8CH control entry identifies the available channel footprint; obtain the current DMX chart and match it to the intended firmware and console profile.
The light-source entry, 18pcs 10W RGBW 4 in 1 LEDs, is not by itself a circuit-load calculation. Use the complete input-power and supply data in the specification table when planning distribution. Include clamps, safety devices, cables, cases and accessories when reviewing rigging and logistics. If a required value remains marked as pending, keep it as an approval item and obtain written confirmation before ordering.
Project and purchasing review
Prepare a short requirement sheet covering application, environment, mounting, throw, control, supply, required documents, accessories, quantity, spares and delivery scope. Compare alternatives at the same operating conditions. A feature is valuable only when it supports a real cue, reduces project risk or improves operation. Do not infer price, certification, warranty or performance that is not present in the approved record.
Before accepting production, confirm model identity, external condition, included accessories and control behavior. Run movement and optical functions through the modes the project will use, record the result and update the as-built patch. Keep the final data sheet, DMX chart and service contacts with the asset record so operators and technicians can trace the basis of the selection.
