P1915IP
P1915IP is an IP66 LED Waterproof Wash light with 19pcs 15W RGBW LEDs, RGBW linear dimming, uniform RGBW color mixing system and rainbow effect, preset color macro, ring control, 10/25/35/45/60° beam angle options, DMX512 control, RDM protocol and 4CH/8CH control modes.
| Power consumption | 300W |
|---|---|
| Power input | AC100-240V, 50/60HZ |
| Light source | 19pcs 15W LED, RGBW |
| LED configuration | 19pcs 15W RGBW LEDs |
| Color system | RGBW linear dimming; Uniform RGBW color mixing system and rainbow effect; Preset color macro; Ring controlled |
| Beam angle | 10/25/35/45/60° |
| Control | DMX512 control, RDM protocol, built-in programs |
| DMX channels | 4CH/8CH |
| Dimming | 0-100% linear dimming |
| Strobe | 1-25Hz |
| Display | LCD display; Graphical menu display; Four buttons touch panel |
| IP rating | IP66 |
| Product size | 315 x 151 x 316mm |
| Net weight | 7KG |
Specifications are based on the current P1915IP product record and may change without prior notice. CRI, Luminous flux, Packing size, Gross weight, Certification, Warranty, MOQ, Lead time require final sales confirmation.
Product questions
What type of fixture is P1915IP?
P1915IP is a LED Waterproof Wash Light. P1915IP is an IP66 LED Waterproof Wash light with 19pcs 15W RGBW LEDs, RGBW linear dimming, uniform RGBW color mixing system and rainbow effect, preset color macro, ring control, 10/25/35/45/60° beam angle options, DMX512 control, RDM protocol and 4CH/8CH control modes.
What light source does P1915IP use?
The published light-source specification for P1915IP is 19pcs 15W LED, RGBW.
What is the IP rating of P1915IP?
The published protection rating for P1915IP is IP66. Confirm installation conditions and the latest production specification with iTOPLITE before use.
What beam or zoom range does P1915IP provide?
The published optical range for P1915IP is 10/25/35/45/60°.
Which DMX channel modes does P1915IP support?
The current product record lists 4CH/8CH. Contact iTOPLITE for the latest DMX chart and firmware-specific documentation.
Where is P1915IP typically used?
Recommended applications include Outdoor events, Stage performance and concerts, Architectural lighting and wall washing, Rental projects. Final fixture selection should account for throw distance, required output, control plan and environmental conditions.
Planning with P1915IP
Overview
P1915IP is a led waterproof wash light in the Outdoor Wash range. Its published light-source specification is 19pcs 15W LED, RGBW, the optical record lists 10/25/35/45/60°, and the enclosure rating is IP66. The available control record lists 4CH/8CH. These values describe the current product record and should be checked against the production version offered for a project. Selection should begin with the required visual task and site conditions rather than one headline value.
Where it is used
The published applications include Outdoor events, Stage performance and concerts, Architectural lighting and wall washing, Rental projects. In a real design, each application changes the priorities. Touring teams may focus on handling, repeatable setup and control-library consistency. Fixed installations may give more weight to access, operating cycles and planned maintenance. Outdoor work also requires compatible connections, distribution and procedures; the fixture rating does not protect unrelated parts of the system.
Reading the specifications
The 10/25/35/45/60° optical specification should be evaluated at the actual throw distance and target size. Request photometric data or test a production-representative sample when beam coverage or camera exposure is critical. The published IP66 rating describes enclosure protection under defined conditions, not permission to ignore mounting orientation, seals, connectors or severe-weather decisions. The 4CH/8CH control entry identifies the available channel footprint; obtain the current DMX chart and match it to the intended firmware and console profile.
The light-source entry, 19pcs 15W LED, RGBW, is not by itself a circuit-load calculation. Use the complete input-power and supply data in the specification table when planning distribution. Include clamps, safety devices, cables, cases and accessories when reviewing rigging and logistics. If a required value remains marked as pending, keep it as an approval item and obtain written confirmation before ordering.
Project and purchasing review
Prepare a short requirement sheet covering application, environment, mounting, throw, control, supply, required documents, accessories, quantity, spares and delivery scope. Compare alternatives at the same operating conditions. A feature is valuable only when it supports a real cue, reduces project risk or improves operation. Do not infer price, certification, warranty or performance that is not present in the approved record.
Before accepting production, confirm model identity, external condition, included accessories and control behavior. Run movement and optical functions through the modes the project will use, record the result and update the as-built patch. Keep the final data sheet, DMX chart and service contacts with the asset record so operators and technicians can trace the basis of the selection.
